Transparent DMX512 SPI DC24V 24V RGB RGBW Artnet removable LED Mesh Grid Matrix Screen 30/40/50/60/80/100/200mm Pixel Pitch

Foldable transparent LED Grid display Features:

• Pixel Pitch: 50mm
• Pixel Density: 400 dot/m²
• LED Type:  1/2/3 RGB 3IN1 SMD3535
• Brightness: 1000 / 1800 / 2500 (cd/m²)
• Max. Power Consumption: 180 / 240 / 300 (W/m²)
• Ave. Power Consumption: 60 / 80 / 100 (W/m²)
• Transparency: 75%
• Viewing Distance: 10m~300m
• Screen Weight: 4.6 kg/m²
• Module Resolution: 8dots*250dots max.
• Fire Protection Rating: UL94-V0
• IP Rate: IP67
• Dot Size: 20mm(L) * 18mm *18mm(H)
• Viewing Angle: 120°(H)/120°(V)
• Housing Material: Transparent PC
• Refresh Rate: ≥1920Hz
• Gray Scale: 16 Bits
• Working EnvironmentTemperature:  -30℃~+60℃，Humidity10~90% RH
• Input (Working) Voltage: AC110~ 240V, 50/60Hz (DC12V)
• Scan Mode: Static Scanning

 Accessory:

Installation Guide

Application:
